Reachoptics' 100G QSFP28 AOC Cables is a high data rate parallel active optical cable (AOC), to overcome the bandwidth limitation of traditional copper cable. The AOC is terminated with a QSFP28 module at one end and four SFP28 modules at the other. With the QSFP28 terminal, it offers 4 independent data transmission channels and 4 data receiving channels via multimode ribbon fibers, each capable of 26Gb/s operation. The fiber ribbon then fans out to four fiber cables, each of which is terminated with an SFP28 module.

Consequently, an aggregate data rate of 100Gb/s over up to 100m transmission can be achieved by this product, to support the ultra-fast computing data exchange. The product is designed with form factor, optical/electrical connection according to the QSFP28 and SFP28 Multi-Source Agreements (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference.

• Four-channel full-duplex active optical cable
• Transmission data rate up to 26Gbit/s per channel
• Reliable VCSEL array technology using multimode fiber
• Available in standard lengths of 3, 5, 10, 15, 20, 30, 50,70m
• Low power consumption <3.5W
• Operating case temperature 0°C to +70°C
• 3.3V power supply voltage
• RoHS 6 compliant
• Hot Pluggable QSFP form factor

• 100G Ethernet
• Data center
• Infiniband QDR/DDR/SDR
• 4G/8G/10G Fibre Channel
