1.25G BIDI SFP 40km 1310nm TX / 1490nm RX Cisco Compatible Optical Transceiver

1.25G BIDI SFP 40km 1310nm TX / 1490nm RX Cisco Compatible Optical Transceiver
Item : RSB-3412x-40x(D)
Name Value

Form Factor SFP BI-DI
Data Rate 1.25G
Distance 40km
Wavelength T1310/R1490
LD DFB
PD PIN
Connector LC/SC
DDM Y/N
GE LC BIDI SFP 1310/1490nm 40km optical transceiver

High Quality with ISO9001, TUV, CE, FCC, UL, RoHs certificates
100% compatible with industry leading brands, such as Cisco, HP, Huawei, Extreme, Juniper, etc.
Please specify your equipment's brand w

Product Description

RSB-3412x-40C(D)

1.25Gbps SFP Bi-Directional Transceiver, 40km Reach

1310nm TX / 1490 nm RX

Features

Dual data-rate of 1.25Gbps/1.063Gbps operation
1310nm DFB laser and PIN photodetector for 40km transmission
Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
Compatible with SONET OC-24-LR-1
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard : 0 to +70°C

Applications

Gigabit Ethernet
Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems

Description

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 40km transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Ordering information

Part Number	Product Description
RSB-3412S-40C	1310nm, 1.25Gbps, SC,40km, 0°C~+70°C
RSB-3412S-40CD	1310nm, 1.25Gbps, SC,40km, 0°C~+70°C, With Digital Diagnostic Monitoring
RSB-3412L-40C	1310nm, 1.25Gbps, LC,40km, 0°C~+70°C
RSB-3412L-40CD	1310nm, 1.25Gbps, LC,40km, 0°C~+70°C, With Digital Diagnostic Monitoring

Name	Value
Form Factor	SFP BI-DI
Data Rate	1.25G
Distance	40km
Wavelength	T1310/R1490
LD	DFB
PD	PIN
Connector	LC/SC
DDM	Y/N
