| Name | Value |
| Form Factor | SFP BI-DI |
| Data Rate | 155M |
| Distance | 20km |
| Wavelength | T1310/R1550 |
| LD | FP |
| PD | PIN |
| Connector | LC/SC |
| DDM | Y/N |
The SFP-BIDI transceivers are high performance, cost effective modules supporting data-rate of 155Mbps and 20km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
| Part Number | Product Description |
| RSB-3501S-20C | 1310nm, 155Mbps, SC, 20km, 0 to 70°C |
| RSB-3501S-20CD | 1310nm, 155Mbps, SC, 20km, 0 to 70°C, With Digital Diagnostic Monitoring |
| RSB-3501L-20C | 1310nm, 155Mbps, LC, 20km, 0 to 70°C |
| RSB-3501L-20CD | 1310nm, 155Mbps, LC, 20km, 0 to 70°C, With Digital Diagnostic Monitoring |
| RSB-3501S-20T | 1310nm, 155Mbps, SC, 20km, -40 to +85°C |
| RSB-3501S-20TD | 1310nm, 155Mbps, SC, 20km, -40 to +85°C, With Digital Diagnostic Monitoring |
| RSB-3501L-20T | 1310nm, 155Mbps, LC, 20km, -40 to +85°C |
| RSB-3501L-20TD | 1310nm, 155Mbps, LC, 20km, -40 to +85°C, With Digital Diagnostic Monitoring |
