155M BIDI SFP 80km 1550nm TX / 1490nm RX Cisco Compatible Optical Transceiver

155M BIDI SFP 80km 1550nm TX / 1490nm RX Cisco Compatible Optical Transceiver
Item : RSB-5401x-80C(D)
Name Value

Form Factor SFP BI-DI
Data Rate 155M
Distance 80km
Wavelength T1550/R1490
LD DFB
PD PIN
Connector LC/SC
DDM Y/N
1. Big Sales 80km 1490/1550 Optics BIDI SFP
2. 1490nm Tx 1550nm Rx 80km 155M WDM SFP
3. 155M BIDI SFP Transceiver
4. 155M,Tx:1550nm/Rx:1490nm, LC, 80km
5. GE/FC,CE,RoHS/FDA/UL/FCC
6. High Quality OEM ODM

Product Description

RSB-5401x-80C(D)

155Mbps SFP Bi-Directional Transceiver, 80km Reach

1550nm TX / 1490 nm RX

Features

Up to 155Mbps data-rate
1550nm DFB laser and PIN photodetector for 80km transmission
Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard : 0 to +70°C

Applications

SDH STM-1, S-1.1,L-1.1, L-1.2
SONET OC-3 IR1,LR1,LR2
Other optical links

Description

The SFP-BIDI transceivers are high performance, cost effective modules supporting data-rate of 155Mbps and 80km transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Ordering information

Part Number	Product Description
RSB-5401S-80C	1550nm, 155Mbps, SC, 80km, 0°C~+70°C
RSB-5401S-80CD	1550nm, 155Mbps, SC, 80km, 0°C~+70°C, With Digital Diagnostic Monitoring
RSB-5401L-80C	1550nm, 155Mbps, LC, 80km, 0°C~+70°C
RSB-5401L-80CD	1550nm, 155Mbps, LC, 80km, 0°C~+70°C, With Digital Diagnostic Monitoring

Name	Value
Form Factor	SFP BI-DI
Data Rate	155M
Distance	80km
Wavelength	T1550/R1490
LD	DFB
PD	PIN
Connector	LC/SC
DDM	Y/N
