RX2D-xx96-80CD
10Gbps DWDM X2 ZR 80km Transponder
Features
- X2 MSA Compliant
- 70-PIN connector
- SC duplex receptacle package
- XAUI 4x3.125Gb/s and TX/RX 10Gb/s data rate
- Wavelength selectable to C-band ITU-T grid wavelengths
- Cooled EA-DFB/APD
- Power supply: +5.0 V, +3.3 V, APS:+1.2 V
- Power Dissipation 4W Maximum
- 0ºC to 70ºC Operating Case Temperature
- Digital Diagnostic Monitoring
- Management and control with MDIO 2-wire bus
- XAUI electrical interface 4 x 3.125Gb/s Ethernet
- 80km ZR 10GBE
- RoHS compliant and lead free
Applications
- 10 Gb/s Ethernet transmission systems
Mechanical Dimensions
Ordering information
| Part Number |
Product Description |
| RX2D-xx96-80CD |
10Gbps, DWDM X2, 80km(ZR), 0ºC ~ 70ºC, Cooled EA-DFB/APD |
| xx=17~61 (ITU Channel C-band) |
