• Wavelength selectable to C-band ITU-T grid wavelengths
• Suitable for use in 100GHz channel spacing DWDM systems
• XFP MSA Compliant
• data rate from 9.95 Gbps to 11.3Gbps
• No Reference Clock required
• Cold Start up Wavelength Compliance
• DWDM-rated EML transmitter and PIN receiver
• link length up to 40km
• Low Power Dissipation 3.5W Maximum
• -5ºC to 70ºC Operating Case Temperature
• Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
• RoHS compliant and lead free

• SONET OC-192&SDH STM 64
• 10GBASE-ER/EW
• 40 km 10G Fiber Channel
• DWDM Networks

Reach Optics' DWDM XFP Transceiver exhibits excellent wavelength stability, supporting operation at 100 GHz channel, cost effective module. It is designed for 10G DWDM SDH, 10GBASE-ER/EW and 10G Fiber- Channel applications.

The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements.

Reach Optics' DWDM XFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
